RG213 & LM400 Coaxial Antenna Cables

Compare HiTech Wireless 50-ohm cable assemblies by cable type, connector, and length. Each assembly uses the same connector on both ends.

Find Your Cable

LM400 comes in 30 ft and 50 ft lengths with either N-type male or PL-259 (UHF male) connectors.

SKU Cable Connectors Length Product
RG213-N-30 RG213 N-type male 30 ft Ask about this SKU
RG213-N-50 RG213 N-type male 50 ft Ask about this SKU
RG213-UHF-30 RG213 PL-259 (UHF male) 30 ft View product
RG213-UHF-50 RG213 PL-259 (UHF male) 50 ft View product
LM400-N-30 LM400 N-type male 30 ft Ask about this SKU
LM400-N-50 LM400 N-type male 50 ft View product
LM400-UHF-30 LM400 PL-259 (UHF male) 30 ft Ask about this SKU
LM400-UHF-50 LM400 PL-259 (UHF male) 50 ft View product

Match the Connector to Your Equipment

Check the ports at both ends of the run. If they differ, you’ll need a mixed-connector assembly or a suitable adapter.

RG213 vs. LM400 Cable Specifications

Both are about 0.405 in. (10.3 mm) thick at the cable jacket. The main differences are the center conductor, insulation, and shield. The diameter is for the cable body. Allow extra clearance for the installed connectors when routing through conduit or a wall opening.

Specification RG213 (Belden 8267 reference) LM400 (supplier construction)
Nominal impedance 50 ohms 50 ohms
Nominal cable outside diameter 0.405 in. (10.3 mm) 0.405 in. (10.3 mm)
Center conductor 13 AWG stranded bare copper, 0.089 in. (2.26 mm) Copper-clad aluminum, 0.108 in. (2.74 mm)
Dielectric Solid polyethylene, 0.285 in. (7.24 mm) Foamed polyethylene, 0.290 in. (7.37 mm)
Shield construction Bare copper braid, 95% coverage Bonded aluminum foil with tinned copper braid
Outer jacket PVC Black PVC or polyethylene, depending on the assembly

Published Bulk-Cable Benchmarks

Compare loss at your operating frequency and over the same cable length. The figures below apply to the named bulk cables. For the loss of a HiTech Wireless LM400 assembly, use the specifications for that assembly.

Specification Belden 8267 RG213 Times Microwave LMR-400
Signal loss at 50 MHz 1.3 dB per 100 ft 0.9 dB per 100 ft
Signal loss at 900 MHz 7.6 dB per 100 ft 3.9 dB per 100 ft
Cable weight, without connectors 10.4 lb per 100 ft 6.8 lb per 100 ft
Minimum bend radius during installation 4 in. 1 in.
Velocity factor 66% 84%

For a 50 ft run at 900 MHz, these bulk-cable figures work out to about 3.8 dB for Belden 8267 RG213 and 2.0 dB for Times Microwave LMR-400, before connector losses. Use the bend radius and loss figures specified for the assembly you install.

Which Cable Should I Choose?

Choose RG213 if your installation calls for a stranded copper center conductor. Consider LM400 when feed line loss matters, especially on longer or higher-frequency runs. When loss, bend radius, or jacket rating is critical, confirm those specifications for the exact assembly before ordering.

Plan Your 30 ft or 50 ft Feed Line

Measure from the radio to the antenna along the route the cable will actually follow. Include vertical sections, bends, and enough slack to service the connectors. At the same frequency, a 30 ft run has about 40% less cable attenuation in dB than a 50 ft run of the same cable. Choose 50 ft when the route needs it.

Estimate Feed Line Loss

Multiply the published loss per 100 ft at your operating frequency by the cable length in feet divided by 100. Then account for the insertion loss of any connectors, adapters, or other components in the RF path.

Using Belden 8267 RG213 as a reference at 900 MHz, the cable portion is about 2.3 dB at 30 ft and 3.8 dB at 50 ft. Use the data for your exact assembly when calculating how much power reaches the antenna.

What to Check Before Ordering

Need help matching a cable to your equipment? Contact HiTech Wireless with your equipment model, connector types, and cable length.
